Sichuan Trixon Communication Technology Corp.,Ltd High-tech enterprise; the leading manufacturer of optical transceivers for data communications
2 Years
| Ask Lasest Price | |
| Brand Name : | Trixon |
| Model Number : | TCS-GEM1-00NCR |
| Certification : | UL,TUV,FCC,CE,ROHS |
| Payment Terms : | L/C D/P |
| Supply Ability : | Negotiable |
| Delivery Time : | Negotiable |
| Price : | Negotiable |
TCS-GEM1-00NIR 10G 100m Effective Copper Communication Device Enhancing Communication with Copper Transceiver
Copper Transceiver is a advanced copper communication device designed for operating temperature of -40°C to +85°C. It is made of high-quality copper material and features a RJ45 connector. It has a length of 100m, making it ideal for long-distance data connections. Copper Transceiver is perfect for high-speed data transmission with excellent signal quality. This device is designed to provide superior performance and reliability with maximum flexibility. It is a reliable and cost-effective solution for copper communication applications.
| Attribute | Value |
|---|---|
| Product Name | Copper Transceiver |
| Connector Material | Copper |
| Data Rate | 1000 Mbps |
| Cable Length | 100 Meters |
| Operating Temperature | -40°C to 85°C |
| Connector Type | RJ45 Connector |
High Speed Electrical Interface, Transmission Line-SFP
| Parameter | Symbol | Min | Typ. | Max | Unit |
| Line Frequency (note6) | Vout | - | 125 | 0 | MHz |
| Tx Output Impedance (note7) | ZOut | 90 | 100 | 110 | Ω |
| Rx Input Impedance (note7) | ZIn | 90 | 100 | 110 | Ω |
High Speed Electrical Interface, Host-SFP
| Parameter | Symbol | Min | Typ. | Max | Unit |
| Differential data input swing | Zin | 500 | - | 2400 | mV |
| Differential data Output swing | ZOut | 350 | - | 1400 | mV |
| Waiting time For Restarting (note8) | - | - | 10 | us | |
| Rise/Fall Time | - | - | 180 | ms | |
| Tx Input Impedance | ZIn | 90 | 100- | 110 | Ω |
| Rx Output Impedance | ZOut | 90 | 100 | 110 | Ω |
Industrial Automation: TCS-GEM1-00NIR can be used in industrial automation systems to improve communication between control systems, sensors and other industrial equipment. It supports reliable data transmission and ensures real-time monitoring and control of industrial processes.
Intelligent transportation systems: This copper communications device can play a role in intelligent transportation systems, connecting various components such as traffic signals, toll collection systems and information displays. It supports high-quality data transmission, enabling real-time traffic management, congestion control and traveler information release.
IoT applications: TCS-GEM1-00NIR can be used in IoT applications to connect various IoT devices and sensors. It provides reliable communication connections and supports data collection, transmission and integration of cloud platforms for IoT solutions such as smart cities, smart buildings and industrial IoT.
Remote monitoring and video transmission: This copper communication device can be used for remote monitoring and video transmission applications, connecting surveillance cameras, video recorders and monitoring centers. It supports high-speed data transmission, ensuring reliable real-time video surveillance and remote viewing.
Industrial Network: TCS-GEM1-00NIR can be used in industrial networks to provide reliable communication connections to industrial switches, routers and other network devices. It enhances the reliability and performance of industrial networks, supporting high-speed data transmission in local area networks (LANs).
Interfaces and form factors match.
Support different transmission speeds.
Accommodates different lengths and types of cables.
Optimize signal integrity and interference immunity.
Power consumption management and energy efficiency optimization.
Enhance environmental adaptability.
Support specific protocols or industry standards
At Copper, we strive to provide the best possible technical support
and service for our customers. Our team of experts is available to
answer any questions or concerns you may have about your Copper
Transceiver.
We offer 24/7 technical support via telephone, email, and live
chat, so you can get the assistance you need when you need it. Our
team is always on hand to provide quick and accurate answers to any
of your questions.
We also provide regular software updates and patches to ensure that
your Copper Transceiver is always running at peak performance. Our
team is dedicated to keeping your device up-to-date and secure.
If you ever have a problem with your Copper Transceiver, we are
here to help. Our team of experts is available to provide
troubleshooting assistance and offer technical advice to ensure
that your device is functioning properly.
At Copper, we strive to provide the highest quality technical
support and service for our customers. If you ever have any
questions or concerns, don't hesitate to contact us.
Packaging and Shipping for Copper Transceiver:
The Copper Transceiver is packaged in a sturdy cardboard box to
ensure that it is protected during the shipping process. The box
measures 8 x 8 x 8 inches and contains foam cushioning to provide
extra protection. The box is labeled with the product name and
model number. Once the box is sealed, it is shipped via a reliable
shipping provider. The estimated delivery time is within 2-3
business days.
Reference Datasheet file code:DS070012 (1000M Copper)
|
|
